GMA-D + PDT 4 stations

Enteral and parenteral alimentation bags

back to MEDICAL SECTOR

For the production of feeding bags in EVA film

  • High Frequency welding press hydraulically operated
  • High Frequency generator built inside press frame
  • Cutting press hydraulically operated
  • Turntable with 4 working stations with adjusting turning speed
  • 2 hydraulic power pack
  • Refrigerating welding press and working station with liquid circulation (optional)
  • Control panel with PLC and touch screen
Welding press maximum closing force (adjustable): 2500 kg
Welding press electrode-holder plate dimension: 700x800 mm
Cutting press maximum closing force (adjustable): 10000 kg / 20000 kg
Cutting press punch-holder plate dimension: 700x800 mm
Turntable working stations dimension: 700x800 mm
Output power of the generator: 20 kW
Feeding voltage (on demand other voltages): 400 V (+/- 5%) – 3 PHASES + EARTH - 50 Hz
